Leírás
For starters
- Color-wheel with motor for T-36
- Spot and motor delivered with installed power cord and safety plug
- Use with alternative illuminants having differing beam angles (flood) is possible
- For application areas such as: Clubs/dancing school; decoration; party room; restaurants, bars and hotels
- Very quiet working noise
color wheel
- Color wheel with red, green, yellow, blue
illuminant
- Dimmable
- Hot restrike
- Very high color rendering index (CRI)
spotlight
- The device is cooled by passive convection cooling
- Control via plug and play
- With mounting bracket
motor for color wheel
- Control via plug and play
Scope of delivery
- 1 x spotlight
- 1 x illuminant
- 1 x motor for color wheel
- 2 x nut
- 1 x color wheel
- 1 x safety bond
- 1 x chain link
- 1 x lamp clamping ring
- 1 x user manual
Manuals
ManualsParaméterek
| Weight | 1.55 kg |
| Noise classification | Class 1 (very slight noise, suitable for noise-sensitive environments) |
| Spotlight | |
| Power supply | 230 V AC, 50 Hz |
| Power consumption | Max. 30 W |
| IP classification | IP20 |
| Protection class | Protection class I |
| Suitable lamp | Max. 6.4 V/30 W PAR-36 G-53 STC |
| Power connection | Fixed power supply cord with safety plug |
| Cable construction | 3 x 0.75 mm² H05VV-F |
| Cable length | Approx. 0.9 m |
| Base | Wires |
| Cooling | Passive convection cooling |
| Control | Plug and play |
| Housing color | Black |
| Attachment system | Mounting bracket |
| Output | 6.4V AC; |
| Dimensions | Length:16 cm |
| Width | 15.5 cm |
| Height | 17 cm |
| Weight | 1 kg |
| Mounting bracket | |
| Diameter mounting holes | 3 x Ø10mm; 1 x Ø8mm |
| Material | Metal, 2 mm |
| Illuminant | |
| Voltage (lamps) | 6.4 V |
| Nominal wattage | 30 W |
| Base | G-53 STC |
| Lamp type | Halogen lamp; clear lamp |
| Lamp specification | Dimmable |
| Hot restrike | |
| Beam angle (1/2 peak) | 6° |
| Color of light | Warm white WW <3300 K |
| Color rendering index (CRI) | 99 Ra |
| Energy efficiency class (A - G) | G |
| Motor for color wheel | |
| Power supply | 230 V AC, 50 Hz |
| Power consumption | 4 W |
| IP classification | IP20 |
| Protection class | Protection class I |
| Power connection | Fixed power supply cord with safety plug |
| Cable construction | 3 x 0.75 mm² H05VV-F |
| Cable length | Approx. 0.9 m |
| Speed | 2.5 RPM |
| Control | Plug and play |
| Maximum load | 1 kg |
| Housing color | Black |
| Dimensions | Length:10 cm |
| Height | 7.5 cm |
| Weight | 0.3 kg |
| Color wheel | |
| Color generation | Color wheel with red, green, yellow, blue |
| Diameter mounting holes | 1 x Ø8mm |
| Material | Plastic |
| Dimensions | Width:0.2 cm |
| Diameter | Ø 23 cm |
| Lamp clamping ring | |
| Material | Metal |
| Color | Silver |
