Leírás
- Digital signal processor FIR Filter; digital signal processor dynamic EQ
- Sample rate: 96 kHz
- The device can be connected via RJ-45 (F) mounting version to the PC
- (19") 48.3 cm rack installation
- For further information about this product, please refer to the Data Sheet under "Downloads"
Scope of delivery
- 1 x controller
- 1 x power cord
- 1 x network cable
Manuals
ManualsParaméterek
| Power supply | 100-240 V AC, 50/60 Hz |
| Power consumption | Max. 35 W |
| Protection class | Protection class I |
| Power connection | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Frequency range | 20 - 20000 Hz |
| S/N ratio | >100 dB |
| THD | <0.003 % at 1 kHz |
| Network connection | Protocol:Ethernet TCP/IP via RJ-45 (F) mounting version |
| DSP | Digital signal processor FIR Filter; digital signal processor dynamic EQ |
| Gain | Input:-70 dB to +12 dB |
| Output | -70 dB to +12 dB |
| Filter | Linkwitz-Riley; Butterworth; Bessel; 6db/oct; 12db/oct; 18db/oct; 24db/oct; 48db/Okt |
| Delay | Output:0 - 2000 ms |
| Input | 0 - 1000 ms |
| Dynamic range | Input:120 dB |
| Output | 120 dB |
| Sample rate | 96 kHz |
| Control elements | Power switch, encoder, mute control |
| Status LED | Clip, limit, level meter, Mute |
| Connections | Input:line via 4 x 3-pin XLR |
| Output | line via 8 x 3-pin XLR |
| Input | XLR (AES/EBU) via 2 x 3-pin XLR |
| Crossover frequency | 20-20000 Hz |
| Max. level | Input:+20 dBu |
| Output | +20 dBu |
| PC connect | Via RJ-45 (F) mounting version |
| Housing design | (19") 48.3 cm rack installation |
| Dimensions | Width:48.2 cm |
| Depth | 20.5 cm |
| Height | 4.4 cm |
| Weight | 3.19 kg |
